Operation: Engine oil receives a secondary filtration before passing through a check valve on its way to the Turbocharger. The accumulator section is charged with oil via a bleed orifice while the engine is running. On engine shut down the check valve closes and oil stored in the accumulator continues to flow to the Turbocharger for up to five minutes (thus cooling and lubricating the Turbocharger bearings for this period).
Overall Height - 270mm
Accumulator Diameter - 115mm
Filter Diameter - 95mm Mounting Flange - 110mm x 87mm
Bolt Holes Diameter (x4) - 10mm
Oil Inlet Connection Female - 3/8" NPT
Oil Outlet Connection Female - 3/8" NPT
Oil Capacity (charged @ 60psi) - 750ml
Oil Filter (recommended) - Fleetguard LF3376
Oil Filter Micron Rating - Nominal: 30 - Absolute: 55
- WEIGHT2.601 kg
