PART NUMBER INFORMATION

Part No: 5456842H

Alternate Part No: 3799079H , 3799079 , 3798723 , 3774630 , 3782635 , 3774616 , 3774617 , 3774631 , 3782636 , 3798710 , 3798717 , 3798718 , 3767626 , 3767627 , 3767619 , 3767806 , 2836363 , 2836362 , 4047351 , 4047350 / 3795168 /3792781 , 3795169 / 3792790 , 3792791 , 3792780 / 2840535 , 2838152 , 2838151 / 2840103 , 2843274 , 2840536 , 3774606 , 5456842 , 5354885 , 3767634 , 2840537 , 2842988 , 3774644

OEM Part No: 3799106RX , 3799106 , 4309080 , 2881788 , 2882001 , 4956013 , 4955773 , 5456844 , 4309080RX , 4309080NX , 2881788RX , 2881788NX , 2882001RX , 2882001NX , 4956013NX , 4955773NX , 5456844 , 5456844RX

ADDITIONAL INFORMATION

This turbocharger is supplied by Holset without the electric actuator. The electric actuator can be purchased individually, see Associated Products.

Turbocharger assembly 5354889H, supplied complete with 12V electric actuator pre-fitted and calibrated.

Turbocharger assembly 5354890H, supplied complete with 24V electric actuator pre-fitted and calibrated.

VEHICLE INFORMATION

Manufacturer: Cummins

Application: Highway

Model: CM871 Series

Engine: ISX15 EGR

Emissions: EPA07

Displacement: 15.0L

Fuel Type: Diesel

TURBO INFORMATION

Brand: Holset

Model: HE500VG

Technology: Variable geometry turbine (VGT)

Actuation: N/A

Condition: New outright

Gaskets: Supplied with turbocharger (as pictured)

This turbocharger is brand new and genuine, it comes complete with 12 months warranty and after sales service.

TURBO / ACTUATOR POSITIONAL INFORMATION

Turbocharger Location: Mid mount

Exhaust outlet Location: Rear out

Electric Actuator Location: Side mount

ASSOCIATED PRODUCTS

Electric Actuator 12V 4034289H

Electric Actuator 24V 4034290H
